Factory Price IP68 3 Ways M25 Waterproof Panel Mount Connector T Shape Male Female Outdoor Waterproof Cable Connectors
Product Details:
| Place of Origin: | China |
| Brand Name: | Xiangqian |
| Certification: | UL |
| Model Number: | M25 T Plug |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100PCS |
|---|
|
Detail Information |
|||
| Brand: | Xiangqian | Connector Name: | M25 IP68 Waterproof Connectors |
|---|---|---|---|
| Material: | PA66, Nylon | IP Grade: | IP68 |
| Cable OD: | 6.0mm-14.0mm | Connector Core: | 2-6 Pin |
| Certificates: | UL, TUV | Sample: | Free |
| Delivery Time: | 3-5 Days | ||
Product Description
Factory Price IP68 3 Ways M25 Waterproof Panel Mount Connector T Shape Male Female Outdoor Waterproof Cable Connectors
1. Product Positioning and Function
This type of connector is primarily used for three-way branch connections in outdoor power lines, specifically for wiring with one input and two outputs or one input and multiple outputs.
It is commonly used in applications such as LED street lights, landscape lighting, solar energy equipment, outdoor power distribution, smart poles, and surveillance equipment.
It requires a high IP68 rating for long-term resistance to environmental intrusion, such as rain, moisture, and dust.
2. Construction and Materials
The housing is typically made of PA66 (nylon reinforced material), which offers excellent weather, UV, and impact resistance.
Seals typically utilize silicone or fluororubber O-rings or washers for sealing.
Internal contacts are typically brass or copper alloy (sometimes nickel-plated or tin/silver-plated) to ensure good conductivity and corrosion resistance.
Connections may include threaded locking, push-pull, quick-connect, or pressure plate designs for easy installation and maintenance.
Cable clamping or locking mechanisms (such as compression rings, locknuts, and sealing sleeves) must ensure a seal and mechanical fixation despite vibration and thermal expansion and contraction.
In a T-type connector, there are typically cable holes in three directions, each with a sealing structure. The connector interior can be designed with a single input and two outputs or an equal branching structure.
Parameters:
| Cable OD | Ø6.0-14.0MM |
| Hardware Material | Copper gold plating |
| Contact Resistance | ≤ 10 mΩ |
| Connection Mode | Push Locking |
| Operating Rated | -40-+105 |
| Flame Retardant Grade | UL94 V-0 |
Performance Test Report (Factory Test)
| Parameter | Common typical values or ranges | Notes |
| Voltage Rating | 250 V / 400 V / 450 V | Some models support high voltage levels (such as solar or power systems) |
| Current Rating | 10A-40A |
Depends on conductor cross-sectional area, contact area, and heat dissipation conditions. Some M25 models can reach 41 A in 2/3/4 cores. |
| Contact Resistance | ≤10 mΩ | Requires low contact resistance to reduce heat generation |
| Dielectric Withstanding Voltage | Several thousand volts (e.g. 1.5 kV / 60 s, etc.) | Responding to surges or transient overvoltages |
| Insulation Resistance | ≥10 MΩ / 500 VDC | Prevent leakage and insulation breakdown |
| Operating Temperature | –40°C to +105°C (or higher) | For outdoor environments with temperature changes |
| Ingress Protection | IP68 | Indicates that it can be immersed in water for a long time under specified conditions and prevent dust from entering |
| Media durability / humidity / salt spray test | Often pass salt spray test / high humidity aging test | For long-term outdoor reliability |
