Black Waterproof Plug Connector M20 PA66 Outdoor LED Plug Connector
Product Details:
| Place of Origin: | China |
| Brand Name: | Xiangqian |
| Certification: | RoHS |
| Model Number: | M20 Screw Type |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 450*320*280 |
| Delivery Time: | 10-15 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10000PCS/days |
|
Detail Information |
|||
| Cable Length: | 20cm | Cable Specification: | 2.5mm² |
|---|---|---|---|
| Color: | Black | Connector Gender: | Male |
| Connector Number: | 2 | Connector Type: | M20 Screw Type Connector |
| Contact Resistance: | 2.5mΩ | Current Rating: | 20A |
| Insulation Resistance: | 1000MΩ | Material: | Copper, Plastic |
| Temperature Range: | -25℃~+85℃ | Voltage Rating: | 250V |
| Waterproof Level: | IP68 | Withstand Voltage: | 1500V |
| High Light: | M20 Waterproof Plug Connector,Waterproof LED Plug Connector,PA66 LED Plug Connector |
||
Product Description
| Item: | M20 Assembly Connector | Contact Material: | Pvc/ TPE |
|---|---|---|---|
| Certificate: | CE/ROHS/IP | IP Rating: | IP67/IP68 |
| Withstand Voltage: | 1.5KV | Temperature Range: | -20~+85 |
| High Light: |
Mini M20 waterproof wire connectorsLighting Cable Waterproof Electrical ConnectorIP68 Waterproof Electrical Connector |
||
M20 Black LED Lighting Cable Wire IP68 Waterproof Electrical Connector
Detailed Product Description
1.Product Name:M20 Waterproof Connector
2.Waterproof Rating : IP68
3.Cable: Customsize
4.Waterproof O-Ring: Silicone
5.Installation Size: M20*1
|
||||||||||||||||||||||||||||||||||||||||||||||||
Features:
- Rated current: 20A/10rms.
- IP67/68 rating
- Voltage rating: 300V
- Cable Range: 3~11mm
- UL, TUV, CB, CCC, CE, RoHS approved
Main characteristics
- Sealed against dust and fluid (IP68)
- Vibration resistance,impact resistance,stretching resistance
- Cable assembly support
- Customized cable size and length
Applicaiton of M20 Screw Type Connectors
- LED screen -Audio-visual equipment
- Stage equipment - Street lamp lighting
- Medical equipment - Server
- Solar energy equipment - Ship equipment
- Electric power equipment - Vehicle equipment
- Communications equipment - Heavy machinery
- Industrial ethernet in audio, business, amusement - Industrial indoor and outdoor event in network environment
- Live stage action - DMX lighting
FAQ
Q1.Are you a manufacturer?
A1: Yes, we are a experienced manufacturer with our own molds and production lines.
Q2.How about quality of products?
A2: Our technicians and QC teams test the products one by one using specail device and instruments.
Q3.How about price?
A3: We are a manufacturer and always offer our customers the most competitive factory price.
Q4.How to play an order?
A4: Contact with online service, or sent an email to us,we will confirm you with product price,specs,packing etc.
Q5.May I buy samples from you?
A5: Yes! You are welcome to place sample order to test our superior quality and services.
